Argo CD GitOps: Install, Apps and ApplicationSets

💡 Quick Answer: Install Argo CD (kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml), create an Application CRD pointing to your Git repo, and Argo CD automatically syncs manifests to your cluster. Changes in Git trigger deployments.

Key command: argocd app create my-app --repo https://github.com/org/repo --path k8s --dest-server https://kubernetes.default.svc

Gotcha: Enable auto-sync with syncPolicy.automated for true GitOps; manual sync is default. Use selfHeal: true to revert manual cluster changes.

Argo CD is a declarative, pull-based GitOps continuous delivery tool. It continuously compares the manifests in Git (plain YAML, Helm, Kustomize, Jsonnet) with the live cluster, reports drift, and syncs — so Git is the single source of truth, rollback is a git revert, and the UI shows what is deployed where.

Install Argo CD

# Create namespace
kubectl create namespace argocd

# Install Argo CD
kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

# Wait for pods to be ready
kubectl wait --for=condition=Ready pods --all -n argocd --timeout=300s

# Install the CLI
curl -sSL -o argocd https://github.com/argoproj/argo-cd/releases/latest/download/argocd-linux-amd64
sudo install -m 555 argocd /usr/local/bin/argocd

On OpenShift, install the Red Hat OpenShift GitOps operator from OperatorHub instead — it deploys and upgrades Argo CD for you.

Access Argo CD UI

# Get initial admin password
kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath="{.data.password}" | base64 -d

# Port-forward to UI
kubectl port-forward svc/argocd-server -n argocd 8080:443

# Login via CLI
argocd login localhost:8080 --username admin --password <password> --insecure

Create Application via YAML

# application.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/my-app-manifests
    targetRevision: HEAD
    path: k8s/overlays/production
  destination:
    server: https://kubernetes.default.svc
    namespace: production
  syncPolicy:
    automated:
      prune: true      # Delete resources removed from Git
      selfHeal: true   # Revert manual changes
    syncOptions:
      - CreateNamespace=true
    retry:
      limit: 5
      backoff:
        duration: 5s
        factor: 2
        maxDuration: 3m

Ignore Controller-Managed Fields

If an HPA owns replicas (or a webhook injects fields), the app flaps OutOfSync. Tell Argo CD to ignore them:

spec:
  ignoreDifferences:
    - group: apps
      kind: Deployment
      jsonPointers:
        - /spec/replicas
  syncPolicy:
    syncOptions:
      - RespectIgnoreDifferences=true   # also don't overwrite them on sync

Create Application via CLI

argocd app create my-app \
  --repo https://github.com/myorg/my-app-manifests \
  --path k8s/overlays/production \
  --dest-server https://kubernetes.default.svc \
  --dest-namespace production \
  --sync-policy automated \
  --auto-prune \
  --self-heal

Application with Helm

# helm-application.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-helm-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://charts.example.com
    chart: my-chart
    targetRevision: 1.2.3
    helm:
      values: |
        replicaCount: 3
        image:
          tag: v2.0.0
      parameters:
        - name: service.type
          value: LoadBalancer
  destination:
    server: https://kubernetes.default.svc
    namespace: production

Application with Kustomize

# kustomize-application.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-kustomize-app
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/my-app
    targetRevision: main
    path: k8s/overlays/production
    kustomize:
      images:
        - my-app=my-registry/my-app:v2.0.0
  destination:
    server: https://kubernetes.default.svc
    namespace: production

ApplicationSet for Multiple Environments

# applicationset.yaml
apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: my-app
  namespace: argocd
spec:
  generators:
    - list:
        elements:
          - env: dev
            namespace: dev
          - env: staging
            namespace: staging
          - env: production
            namespace: production
  template:
    metadata:
      name: 'my-app-{{env}}'
    spec:
      project: default
      source:
        repoURL: https://github.com/myorg/my-app
        targetRevision: HEAD
        path: 'k8s/overlays/{{env}}'
      destination:
        server: https://kubernetes.default.svc
        namespace: '{{namespace}}'
      syncPolicy:
        automated:
          prune: true

Git directory generator — one Application per directory under apps/:

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: all-apps
  namespace: argocd
spec:
  generators:
    - git:
        repoURL: https://github.com/myorg/k8s-manifests.git
        revision: main
        directories:
          - path: apps/*
  template:
    metadata:
      name: '{{path.basename}}'
    spec:
      project: default
      source:
        repoURL: https://github.com/myorg/k8s-manifests.git
        targetRevision: main
        path: '{{path}}'
      destination:
        server: https://kubernetes.default.svc
        namespace: '{{path.basename}}'
      syncPolicy:
        syncOptions:
          - CreateNamespace=true

Sync Waves and Hooks

# Use annotations to control sync order
apiVersion: v1
kind: Namespace
metadata:
  name: my-app
  annotations:
    argocd.argoproj.io/sync-wave: "-1"  # Create first
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  annotations:
    argocd.argoproj.io/sync-wave: "0"  # Then deployment
---
apiVersion: batch/v1
kind: Job
metadata:
  name: db-migrate
  annotations:
    argocd.argoproj.io/hook: PreSync  # Run before sync
    argocd.argoproj.io/hook-delete-policy: HookSucceeded
---
apiVersion: batch/v1
kind: Job
metadata:
  name: smoke-test
  annotations:
    argocd.argoproj.io/hook: PostSync  # Run after sync succeeds
    argocd.argoproj.io/hook-delete-policy: HookSucceeded
spec:
  template:
    spec:
      containers:
        - name: test
          image: my-app:latest
          command: ["./smoke-test.sh"]
      restartPolicy: Never

Additional useful sync options beyond CreateNamespace=true:

spec:
  syncPolicy:
    syncOptions:
      - PrunePropagationPolicy=foreground
      - PruneLast=true
      - RespectIgnoreDifferences=true
      - ApplyOutOfSyncOnly=true
      - ServerSideApply=true

App of Apps Pattern

Manage a fleet of Applications by having a root Application point at a directory of other Application manifests:

# apps/root-app.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: root-app
  namespace: argocd
  finalizers:
    - resources-finalizer.argocd.argoproj.io
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/my-app-manifests
    targetRevision: main
    path: apps
  destination:
    server: https://kubernetes.default.svc
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

# apps/my-app.yaml (child Application managed by root-app)
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app
  namespace: argocd
  finalizers:
    - resources-finalizer.argocd.argoproj.io
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/my-app-manifests
    targetRevision: main
    path: manifests/my-app
  destination:
    server: https://kubernetes.default.svc
    namespace: production
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

Multi-Cluster Management

Register an external cluster so Argo CD can deploy to it:

# Add cluster via CLI
argocd cluster add <context-name> --name production-cluster

# Or via Secret
kubectl apply -f - <<EOF
apiVersion: v1
kind: Secret
metadata:
  name: production-cluster
  namespace: argocd
  labels:
    argocd.argoproj.io/secret-type: cluster
type: Opaque
stringData:
  name: production-cluster
  server: https://production.k8s.example.com
  config: |
    {
      "bearerToken": "<service-account-token>",
      "tlsClientConfig": {
        "insecure": false,
        "caData": "<base64-ca-cert>"
      }
    }
EOF

Fan an Application out to every registered cluster with the clusters generator:

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: multi-cluster-app
  namespace: argocd
spec:
  generators:
    - clusters: {}  # All registered clusters
  template:
    metadata:
      name: 'my-app-{{name}}'
    spec:
      project: default
      source:
        repoURL: https://github.com/myorg/my-app-manifests
        path: k8s/overlays/production
        targetRevision: main
      destination:
        server: '{{server}}'
        namespace: production

Projects and RBAC

Scope which repos, clusters, and resource kinds an Application can use with an AppProject, and control who can sync it:

apiVersion: argoproj.io/v1alpha1
kind: AppProject
metadata:
  name: production
  namespace: argocd
spec:
  description: Production applications
  sourceRepos:
    - https://github.com/myorg/my-app-manifests
  destinations:
    - namespace: production
      server: https://kubernetes.default.svc
  clusterResourceWhitelist:
    - group: ""
      kind: Namespace
  namespaceResourceWhitelist:
    - group: "*"
      kind: "*"
  roles:
    - name: developer
      description: Developer access
      policies:
        - p, proj:production:developer, applications, get, production/*, allow
        - p, proj:production:developer, applications, sync, production/*, allow
      groups:
        - developers

apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-rbac-cm
  namespace: argocd
data:
  policy.default: role:readonly
  policy.csv: |
    p, role:admin, applications, *, */*, allow
    p, role:developer, applications, sync, */*, allow
    g, admins, role:admin
    g, developers, role:developer

Monitoring and Notifications

Send Slack alerts on sync status changes with the Argo CD notifications controller:

apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-notifications-cm
  namespace: argocd
data:
  service.slack: |
    token: $slack-token
  template.app-sync-status: |
    message: |
      Application {{.app.metadata.name}} sync status: {{.app.status.sync.status}}
      Health: {{.app.status.health.status}}
  trigger.on-health-degraded: |
    - when: app.status.health.status == 'Degraded'
      send: [app-sync-status]

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-app
  annotations:
    notifications.argoproj.io/subscribe.on-sync-succeeded.slack: deployments
    notifications.argoproj.io/subscribe.on-sync-failed.slack: deployments

CLI Commands

# List applications
argocd app list

# Get app status
argocd app get my-app

# Sync application
argocd app sync my-app

# View app diff
argocd app diff my-app

# Force a re-read of Git (skip the 3-minute poll)
argocd app get my-app --refresh

# Preview rendered manifests (Helm/Kustomize output)
argocd app manifests my-app

# Rollback (auto-sync must be disabled first)
argocd app rollback my-app

# Delete app but keep its resources
argocd app delete my-app --cascade=false

# Clusters
argocd cluster list

Common Issues

App OutOfSync right after a successful sync — a controller mutates the resource (HPA replicas, defaulted fields, injected sidecars). Add ignoreDifferences (above), or enable ServerSideApply=true.

permission denied / forbidden in target namespace — the argocd-application-controller ServiceAccount lacks RBAC there (common with namespace-scoped installs and OpenShift GitOps: label the namespace argocd.argoproj.io/managed-by=<argocd-namespace>). Also check the AppProject destinations and resource whitelists.

Helm values not applied — invalid YAML in helm.values or a wrong key; inspect with argocd app manifests my-app.

argocd app rollback refused — rollback is blocked while syncPolicy.automated is on; revert in Git instead (the GitOps way) or disable auto-sync.

Best Practices

1. Use separate repos for app code and manifests
2. Enable auto-sync for true GitOps
3. Use sync waves for ordered deployments
4. Implement RBAC with Argo CD projects
5. Store secrets with Sealed Secrets or External Secrets
6. Pin chart versions and Git revisions for production (targetRevision: 1.2.3 or a tag, not HEAD)
7. Notifications to Slack/Teams for sync failures and degraded health

Frequently Asked Questions

What is the difference between Argo CD and Flux?

Both are CNCF-graduated pull-based GitOps controllers. Argo CD ships a web UI, SSO/RBAC, AppProjects and ApplicationSets and is Application-centric; Flux is a set of composable controllers (source, kustomize, helm, notification, image automation) driven entirely by CRDs and the CLI, with no built-in UI. See Flux GitOps.

Does Argo CD auto-sync by default?

No. Applications sync manually unless spec.syncPolicy.automated is set. prune: true deletes resources removed from Git and selfHeal: true reverts manual kubectl changes; both are off by default.

How often does Argo CD check Git?

Every 3 minutes by default (timeout.reconciliation in argocd-cm). Configure a Git webhook to https://<argocd>/api/webhook for near-instant syncs.

What is the difference between an Application and an ApplicationSet?

An Application maps one source (repo/path or chart) to one destination. An ApplicationSet is a template plus generators (list, cluster, git, matrix, pull request) that stamps out many Applications — one per environment, cluster or directory.

How do I deploy to multiple clusters?

Register each cluster (argocd cluster add <context> or a Secret labelled argocd.argoproj.io/secret-type: cluster) and use an ApplicationSet with the clusters generator, optionally filtered by cluster labels.
